High Quality 10 Ton LB Model Explosion Proof Single Girder Overhead Crane
1. About high quality 10ton Explosion Proof Single Girder Overhead Crane
Brief introduction:
1). Explosion-proof girder crane includes
LXB Explosion-proof single girder suspension crane
LB Explosion-proof single girder crane and
LHB type Explosion-proof electric hoist double girder crane.
2) For each of the Explosion-proof sign is ExdIIBT4. ExdIICT4. DIPA21TA, T4.
3) Working class M3, work environment temperature -20℃~+40℃.
2. Specification of high quality 10ton Explosion Proof Single Girder Overhead Crane
| Configuration details of the EOT Crane: |
| Steel plate | Anyang/ Handan Q235 steel |
| Hoist lifting motor | Squirrel cage motor,China famous brand |
| Trolley traveling motor | Squirrel cage motor,China famous brand |
| Crane traveling motor | Squirrel cage motor,China famous brand |
| Hoist lifting gear box | China famous brand |
| Trolley traveling gear box | China famous brand |
| Crane traveling gear box | China famous brand |
| Wheel | 50#steel forged wheels, processed and heat treated by HENAN MINE |
| Bearing | China famous brand |
| Brake | Built in mechanical brake,inside motor |
| Wire rope | High strength wire rope, Jiangsu Juli |
| Hook | DG20Mn high strength material fored hook |
| Main Electrical parts | SCHNEIDER |
| Crane traveling limit switch | Included |
| Overload limiter | Included |
| Trolley power supply | Festoon cable |
| Control mode | Wireless remote control |
| Control panel | YES |
| Cable | Crane industry special cable YC or YVFB type,bear temperature up to 60’C |
| Buffer | High quality polyurethane buffer |
| Painting | Manual brush painting,One alkyd iron red primer painting,two alkyd orange enamel finish painting |
| Safe features of the EOT Crane: | |
| Weight overload protection device | √ |
| Emergency stop system | √ |
| Over current Protection,Short-circuit Protection | √ |
| Phase sequence protection | √ |
| Zero position protection,No-Voltage protection | √ |
| Mechanical interlock protection of controller | √ |
| Limit switch for crane long traveling | √ |
| Stopper and Limit switch for trolley cross traveling | √ |
| Lifting up and lower down limit switch | √ |
| High quality polyurethane buffer for crane long traveling protection | √ |
3. FAQ
3.1 Delivery time:
About 30 days after receipt of the advance payment.
3.2 Delivery terms:
FOB TIANJIN/QINGDAO PORT, CHINA./ CFR + Any port
3.3 Payment terms(Via T/T):
30% advance payment by T/T upon confirming order,balance 70% by T/T before delivery.
3.4 Packaging method:
Electrical parts are by high quality fumigation plywood crate.
3.5 Warranty Period:
18 months from the date of delivery from the factory.
Product Tags:
|
|
10 Ton Explosion Proof Single Girder Overhead Crane LB Model Images
|
